• Mobile Mini Box Type PSA Based Oxygen Plant With Wheels Adjustable Pressure
  • Mobile Mini Box Type PSA Based Oxygen Plant With Wheels Adjustable Pressure
Mobile Mini Box Type PSA Based Oxygen Plant With Wheels Adjustable Pressure

Mobile Mini Box Type PSA Based Oxygen Plant With Wheels Adjustable Pressure

Product Details:

Place of Origin: China
Brand Name: KERONG GAS
Certification: ISO9001, CE, ASME
Model Number: KRN

Payment & Shipping Terms:

Minimum Order Quantity: 1 pc
Price: Negotiable
Packaging Details: Wooden box
Delivery Time: 4 weeks
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 1000pcs per year
Get Best Price Contact Now

Detail Information

Name: Box Type PSA Based Oxygen Plant Purity: 90%~95%
Dew Point: -45℃ Or More Material: Stainless Steel Or Carbon Steel
Capacity: 2.5Nm3/hr~60Nm3/hr Pressure: Adjustable
Highlight:

Mobile Mini Box PSA Oxygen Plant

,

PSA Based Oxygen Plant With Wheels

Product Description

Mobile Mini Box Type PSA Based Oxygen Plant With Wheels For Pharmaceutical



Product description

Our Mobile Mini Box Type PSA-Based Oxygen Plant with Wheels is a compact, portable solution designed to meet the demanding oxygen needs of the pharmaceutical industry. Utilizing Pressure Swing Adsorption (PSA) technology, it produces high-purity oxygen (up to 95%) on-site, eliminating the need for external cylinder deliveries. The mini box-type design is equipped with durable wheels for easy mobility across labs, production areas, or cleanrooms. Fully automatic and energy-efficient, this system offers low maintenance and continuous oxygen supply, ensuring a reliable, cost-effective solution for pharmaceutical applications that require precision, flexibility, and high-quality oxygen.



Mobile Mini Box Type PSA Based Oxygen Plant With Wheels Adjustable Pressure 0





Technical Parameters

Model

Capacity

(Nm3/hr)

Purity(%)

Air consumption

(m3/min)

Inlet air requirements Oxygen specs Electricity Inlet/ outlet pipe

Diemensions

(mm)

N.Weight
KROB-1 2.7 90 0.65 Air Inlet Temperature Range: 0℃~40℃;
Air inlet pressure range: 4~7barG;
Air inlet dew point: <+5°C;
Particles: <5 micron;
Oil: <3 mg/m3
Outlet pressure:0.4MPa-0.65MPa
Water content:≤0.07g/m³
CO2:≤10PPm(V/V)
CO:≤1PPm(V/V)
Dust content:≤0.2mg/m³
Noise level:≤78dB(A)
0.2KW/220V/230V/50Hz/60Hz DN15/ DN15 480*730*1800 310
2.6 93
2.5 95
KROB-2 5.4 90 1.3 0.2KW/220V/230V/50Hz/60Hz DN20/ DN15 480*950*1800 450
5.2 93
5 95
KROB-3 8.1 90 1.95 0.2KW/220V/230V/50Hz/60Hz DN20/ DN15 480*1200*1800 600
7.8 93
7.5 95
KROB-4 10.8 90 2.5 0.2KW/220V/230V/50Hz/60Hz DN25/ DN15 480*1400*1800 750
10.3 93
10 95
KROB-5 13.5 90 3.2 0.2KW/220V/230V/50Hz/60Hz DN25/ DN15 480*1700*1800 900
12.8 93
12.5 95
KROB-6 16.2 90 3.9 0.2KW/220V/230V/50Hz/60Hz DN40/ DN15 480*1900*1800 1050
15.1 93
15 95
KROAB-7 17.7 90 4.3 0.2KW/220V/230V/50Hz/60Hz DN40/ DN15 480*2100*1800 1200
17.5 93
16.9 95
KROAB-8 21.6 90 5 0.2KW/220V/230V/50Hz/60Hz DN40/ DN15 480*2300*1800 1400
20.3 93
20 95





Factory Certificates

Mobile Mini Box Type PSA Based Oxygen Plant With Wheels Adjustable Pressure 1Mobile Mini Box Type PSA Based Oxygen Plant With Wheels Adjustable Pressure 2Mobile Mini Box Type PSA Based Oxygen Plant With Wheels Adjustable Pressure 3





FAQ

Q: Are you a factory or a trading company?

A:We are a factory over 20 years industrial experience.


Q: Do you offer OEM service?
A: Yes, we can customize it as your request.



Q: What is your lead time?
A: About 60~90 days after receiving deposit.



Q: What certificates do you have?
A: We have ASME, CE, ISO9001-2015, ISO13485 for medical oxygen generator. And we can apply for specific certificate for different country such as SONCAP for Nigeria, SASO for Saudi Arabia, etc



Q: What about the warranty?
A: Beyond warranty period(For 12-Months against any manufacturing defect from the date equipment acceptance after commissioning or 18-months from the time of the delivery whichever comes first),supplier will provide spare parts, accessories, easily damaged parts via preferential price.



Q:What service do you offer?
A: Pre-sales service, in-sales service, after-sales service. If you become our local distributor, we can introduce end-customers to purchase from you.





Q:Which port is near to you?
A: Qingdao port or Tianjin port. And we can arrange to deliver Guangzhou, Shanghai, Urumqi, or other Chinese cities, too.



Q:Could you offer Origin Certification.
A: we can do as your request.
